380V Rock Wool Production Line with 40~120 meters/min Conveying Speed and 600mm-2400mm Width for Mineral Wool Board

Product Categories
Hebei Greens Building Material Technology Development Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

380V Rock Wool Production Line with 40~120 meters/min Conveying Speed and 600mm-2400mm Width for Mineral Wool Board

Brand Name : Greens

Place of Origin : CHINA

MOQ : 1

Price : US $2000000-4000000

Payment Terms : L/C,T/T

Delivery Time : 90days

Product Name : Rock Wool Insulation Sheet Making Machine External Insulation Panel For Architectural Design

Keyword : Rock wool sound insulation material production line

Voltage : 380v Or Customized

Conveying speed : 40~120 meters/min

Swing belt width : 2800mm

Swing belt motor : 4kw (variable frequency motor)

Raw material : basalt,dolomite

Width : 600mm-2400mm

Contact Now

Rock Wool Insulation Sheet Making Machine External Insulation Panel For Architectural Design

Product Specifications
Attribute Value
Product Name Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Keyword Rock wool sound insulation material production line
Voltage 380v Or Customized
Electric Control PLC control
Condition New
Conveying speed 40~120 meters/min
Swing belt width 2800mm
Swing belt motor 4kw (variable frequency motor)
Product Description

The drum-type cotton collecting machine is a comprehensive system for rock wool panel production, featuring advanced automation and efficient material handling capabilities.

Technical Specifications
  • Product Name: Rockwool Panel Production Line
  • Automatic Grade: Automatic
  • Voltage: 380V
  • Panel Thickness: 30-200mm
  • Felt Size: 1000mm (adjustable)
  • Panel Density: 30-200 Kg/m3
  • Applicable Industries: Manufacturing Plant, Retail, Construction works
  • Finished products: Rock wool board
  • Usage: Building Material Production
System Components

The machine consists of:

  • Slag and cotton separation system
  • Cotton collection mechanism
  • Screen cleaning device
  • Cotton lifting system
  • Automatic refueling and lubrication system
  • Automatic slag discharge device

The sturdy steel structure frame houses a bearing transmission system. The drum features a mesh plate with an installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.
